DC Filter Choke 3H 250mA 100 Ohm
DC Filter Choke 3H 250mA 100 Ohm
| Codice | DC-EI68077TC |
| Prezzo lordo |
58,0000 EUR/PZ
(IVA compresa 22%) |
| Sconto | |
| Prezzo netto |
58,0000 EUR/PZ
(IVA compresa 22%) |
| Disponibilità | 2 PZ |
DC Filter Choke
Like Dagnall C1999 choke from 1969
Used on Marshall 50 and 100 watt amplifiers from 1969-73
Inductance: 3.5 H typ. 0ADC
Resistance: 100...105 Ohm
DC current: 150 mA - >3.4H
DC current: 200 mA - >3.2H
DC current: 250 mA - >3.0 H
Dimensions and schematic: see picture
Weight: 820 g.
Like Dagnall C1999 choke from 1969
Used on Marshall 50 and 100 watt amplifiers from 1969-73
Inductance: 3.5 H typ. 0ADC
Resistance: 100...105 Ohm
DC current: 150 mA - >3.4H
DC current: 200 mA - >3.2H
DC current: 250 mA - >3.0 H
Dimensions and schematic: see picture
Weight: 820 g.
