Transformer 12VA 230 / 2x16V
16V 0.75A / 32V CT 0.375A
Transformer 12VA 230 / 2x16V
| Codice | PS-EI48008F |
| Prezzo lordo |
18,1500 EUR/PZ
(IVA compresa 22%) |
| Sconto | 7% |
| Prezzo netto |
16,8795 EUR/PZ
(IVA compresa 22%) |
| Disponibilità | 10 PZ |
Power Transformer
Power: 12VA
Input: 230V
nominal Output:
- 2 x 6.3V - 0.95A
- 6.3V - 1.9A (parallel)
- 12.6V C.T. - 0.95A (series)
no-load Output: 2x7.7V / 15.4V
Dimensions and schematic: see drawing
Weight: 325g
Power: 12VA
Input: 230V
nominal Output:
- 2 x 6.3V - 0.95A
- 6.3V - 1.9A (parallel)
- 12.6V C.T. - 0.95A (series)
no-load Output: 2x7.7V / 15.4V
Dimensions and schematic: see drawing
Weight: 325g
